Double Coated Urethane Foam Tape 4016 25x33m
3M ID 70006076072

10604755 9315084100038 24mm 25mm 33 metre

High shear strength on metal and high surface energy plastics
Durable foam is ideal for interior mounting applications
Off-white color provides a clean appearance
Ideal for bonding, attaching, and mounting

Specifications
Adhesive Type    Acrylic
Backing Material    Urethane Foam
Backing Thickness (metric)    1.42 mm
Brand    3M™
Carrier Material    Urethane
Elongation at Break    1
Height (Metric)    1.6 mm
Indoor/Outdoor    Both
Industries    General Industrial, MRO
Length    32.9 m
Maximum Operating Temperature (Celsius)    38 Degree Celsius
Net Weight (Metric)    0.48 kg
Primary Liner    62# Densified Kraft Paper
Primary Liner Colour    Green
Product Form    Roll
Shelf Life in Months (from date of manufacture)    24
Temperature Resistance - Initial    380 Degree Fahrenheit
Tensile Strength (metric)    965
Thickness    1.5 mm
Total Tape Thickness without Liner (metric)    1.5 mm
Width    2.5 cm
Details
3M™ Double Coated Urethane Foam Tape 4016 is a thick, double-coated open-cell urethane foam tape with a 62 lb. densified kraft paper liner and is ideal for applications such as mounting interior signage and nameplates. Its 62 mil foam provides handling convenience and cushioning.

We manufactured this tape using our 3M™ Adhesive 100 for a strong, permanent bond that works with the open-cell foam structure to provide you with high shear strength. This tape is a great solution for bonding various surfaces indoors or for exterior applications where it will be protected from the environment. Its conformable foam and adhesive combine to provide long-term holding at temperatures up to 200°F/93°C. The acrylic adhesive is an ideal formula for bonding to various types of surfaces for mounting, joining and holding applications. By using a robust 62 lb. densified kraft paper release liner, this tape provides reliable performance for industrial applications, such as die-cutting and automated dispensers. The liner also helps reduce edge roll and protects the tape from humidity extremes.

Open cell foams are commonly used to create separate between component panels where a degree of separation is needed to dampen or prevent vibration, as a thermal insulation barrier and protect against contamination, but where a measure of airflow is still necessary, such as with electronic components where air flow helps keep components cool.

3M Industrial Adhesives and Tapes in general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in construction, fabrication, arts, and hobby.

3M™ Adhesive 100 is a firm, acrylic, pressure sensitive adhesive system that features high ultimate bond strength, very good high temperature and solvent resistance and very high shear holding power. Bond strength increases substantially with natural aging.3M™ Adhesive 100 is well known in industry for environmental and chemical resistance. For many applications, any one of the products in this grouping will perform satisfactorily when exposed to different chemicals or temperatures. The adhesive offers excellent bond to metal and high surface energy plastics and good temperature and chemical resistance.

In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in construction, fabrication, arts, and hobby.
